TP-LINK (EAP723) BE3600 Dual Band Ceiling Mount Wi-Fi 7 Access Point PoE 2.5GB Port Omada Mesh Multi-RUs

BE3600 Ceiling Mount Wi-Fi 7 Access Point

• BE3600 Dual-Band Wi-Fi 7 (2882 Mbps on 5 GHz + 688 Mbps on 2.4 GHz).
• 1x 2.5G port unlocks the full potential of Wi-Fi 7.
• 160 MHz bandwidth enables many more simultaneous transmissions.
• Multi-RUs ensure the high performance of your network.
• Advanced Functions: Centralized management, Mesh, and Seamless Roaming

Specifications:

• Primary Function: Access Point

• Bands: Dual Band

• Wi-Fi Rating: BE3600

• Max Single Band Wi-Fi Rate: 2882 Mbps

• Max Wired Transfer Rate: 2.5 Gbps

• Interface(s): 1 x 2.5G Ethernet Port

• Wireless Standards: IEEE 802.11 a/b/g/n/ac/ax/be

• Antenna(s):

  • 2.4 GHz: 2x 4.0 dBi
  • 5 GHz: 2x 5.0 dBi

• Button(s): Reset

• Power Supply:

  • 802.3at PoE or 12V/1.5A DC (Note: Power Adapter not included)

• Power Consumption:

  • 18.6W (For PoE)
  • 16.0W (For DC)

• Dimensions: 160 x 160 x 36.7 mm

• Weatherproof: No

• Frequency:

  • 2.4 GHz: Up to 688 Mbps
  • 5 GHz: Up to 2882 Mbps

• EIRP:

  • < 20 dBm (2.4 GHz, EIRP)
  • < 23 dBm (5 GHz, band 1&2, EIRP)
  • < 28 dBm (5 GHz, band 3, EIRP)

• Wireless Functions:

  • 4K-QAM
  • Seamless Roaming
  • MU-MIMO
  • EHT160
  • Mesh
  • OFDMA
  • Load Balance
  • Band Steering
  • Beamforming
  • Airtime Fairness
  • Multiple SSIDs: 16 (8 for each band)
  • Wireless Schedule
  • Reboot Schedule
  • QoS (WMM)
  • Rate Limit
  • Static IP/Dynamic IP
  • RADIUS Accounting
  • MAC Authentication

• Security:

  • Captive Portal Authentication
  • Access Control
  • Maximum number of MAC Filter: 4,000
  • Wireless Isolation Between Clients
  • VLAN
  • Rogue AP Detection
  • WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise

• Management:

  • Omada App
  • Centralized Management (Cloud-Based, Hardware, Software Controller)
  • Cloud Access (Requires controller)
  • Email Alerts
  • LED ON/OFF Control
  • Management MAC Access Control
  • SNMP: v1, v2c, v3
  • System Logging Local/Remote Syslog
  • Web-based Management

• Additional Features:

  • Coverage: 1500 sq. ft
  • Wireless Client Capacity: 250+
  • 160 MHz Bandwidth
  • Multi-RUs

• Environment:

  • Operating Temperature: 040 C (32104 F)
  • Storage Temperature: -4070 C (-40158 F)
  • Operating Humidity: 1090% RH non-condensing
  • Storage Humidity: 590% RH non-condensing

• Package Contents:

  • AP723
  • Installation Guide
  • Ceiling/Wall Mounting Kit
  • (Note: Power Adapter not included)

• Warranty: Limited Lifetime
