Noctua NH-U9S chromax.black Heatsink & Fan Intel & AMD 5 Dual Heatpipes SSO2 Fan Bearings

Noctua NH-U9S chroma.black CPU Cooler

The NH-U9S cChromaxblack is an all-black version of Noctuas award-winning NH-U9S premium-quality quiet CPU cooler. Thanks to the same proven compact 92mm tower heatsink design and NF-A9 PWM fan, it stays true to the NH-U9Ss successful formula of fusing strong cooling performance with excellent quietness of operation and outstanding RAM, case and PCIe compatibility. At the same time, the chroma. black version with its black fan and black coated heatsink combines these assets with a sleek stealth look. Topped off with the renowned SecuFirm2 multi-socket mounting system, Noctuas enthusiast-grade NT-H1 thermal compound and a full 6-year manufacturers warranty, the NH-U9S chroma. Black is a premium choice for customers who seek a compact, highly compatible 92mm heatsink that looks just as great as it cools.

Award-winning NH-U series

The NH-U9S stems from Noctuas award-winning NH-U9 series. First introduced in 2005, the NH-U series has become a standard choice for premium quality quiet CPU coolers and won more than 800 awards and recommendations from leading international hardware websites and magazines.

chroma.black design

The NH-U9S chromax. Black is black from head to toe: Featuring a black coated heatsink, a black fan with black anti-vibration pads, black fan clips and black mounting parts, it is right at home in all-black builds and easy to integrate with other colour schemes.

S version with better compatibility

Like its bigger brothers NH-U12S and NH-U14S, the NH-U9S features a revised, slimmer layout. Whereas the NH-U9B SE2 was 120mm deep with its two stock fans, the NH-U9S is asymmetrically built and measures only 95mm with its single, more efficient NF-A9 fan, thus providing better performance and compatibility at the same time.

100% RAM compatibility

With its 95x95mm footprint, the NH-U9S does not overhang the RAM slots on current Intel and most AMD mainboards. This gives the user full access to the memory modules and guarantees 100% compatibility with tall heat spreaders or optional memory fans. Please note: Some AMD mainboards violate the 96x114mm keep-out zone specified by AMD, so the NH-U9S can only be used with RAM modules of up to 30mm height on these boards. Please consult our compatibility list for details.

100% compatibility with PCIe cards on mini-ITX

Many IntelLGA115x-basedd mini-ITX mainboards have the PCIe slot sitting right next to the 95x95mm socket zone. While larger coolers that exceed this zone are likely to block the PCIe slot, the 95x95xmm sized NH-U9S provides full compatibility with PCIe cards, be it on ATX, microATX or ITX.

NF-A9 premium fan

The highly optimised NF-A9 premium fan features Noctuas proprietary AAO frame as well as sophisticated aerodynamic design measures such as Flow Acceleration Channels, which allows it to further improve the renowned efficiency of Noctuas previous 92mm models and contributes to the NH-U9S superior cooling performance.

PWM support and Low-Noise Adaptor

The NF-A9 92mm fan supplied with the NH-U9S supports PWM for convenient automatic speed control through the mainboard. In addition, the maximum fan speed can be reduced from 2000 to 1550rpm using the supplied Low-Noise Adaptor for even quieter operation.

Dual fan ready

The NH-U9S includes an extra set of fan mounting clips for users who want to achieve even better cooling performance by adding a second, optional NF-A9 PWM fan to create a push/pull setup. Using the y-cable supplied with the NF-A9 PWM retail fan, both fans can be connected to one CPU fan header.

SecuFirm2 mounting system
Noctuas SecuFirm2 mounting systems have become synonymous with quality, safety and ease of use. Supporting Intel LGA115x (LGA1150, LGA1155, LGA1156), LGA2066, LGA2011 (LGA2011-0 & LGA2011-3) and AMD (AM2+, AM3, AM3+, FM1, FM2, FM2+), the SecuFirm2 mounting included with the NH-U9S guarantees perfect contact pressure and maximum convenience on all current sockets.

Compatibility with past and future sockets
Complying with the open SecuFirm standard, the NH-U9S can be made compatible with the older LGA1366 and LGA775 sockets using the optional NM-I3 mounting kit, which is provided by Noctua free of charge. If technically possible, Noctua will also provide upgrade kits for future sockets.

NT-H1 thermal compound
Having received more than 100 awards and recommendations from hardware journalists around the world, Noctuas NT-H1 is a proven professional-grade TIM solution that provides minimum thermal resistance, excellent ease of use and outstanding reliability.

6 years warranty

Noctua products are renowned for their impeccable quality and outstanding longevity. Like all Noctua fans, the supplied NF-A9 features an MTBF rating of more than 150.000 hours and the entire NH-U9S package comes with a full 6-year manufacturers warranty.

Specifications:

• Type: CPU Air Cooler
• Compatibility:
  • Intel: 1851, 1700, 1200, LGA115x
  • AMD: AM5, AM4
• Fan Controller: PWM
• Fan Bearing: SSO2 Bearing
• Rotation Speed: Max 2000 RPM
• Colour: Black
• LED Lighting: None
• Material:
  • Copper (base and heat pipes
  • Aluminium (cooling fins)
  • Soldered joints & nickel plating
• Weight: 618 g
• Dimensions:
  • Height (without fan): 125 mm
  • Width (without fan): 95 mm
  • Depth (without fan): 68 mm
  • Height (with fan): 125 mm
  • Width (with fan): 95 mm
  • Depth (with fan): 95 mm
• Fan Dimensions: 92 x 92 x 25 mm
• Air Flow: Max 46.4 CFM
• Noise Level: Max 22.8 dB(A)
• Warranty: 6 Years
